The S62200 series stainless steel bearings are an extended version of the S6200 series bearings. For instance, both the S62200 and S6200 bearings share the same outer diameter and inner diameter, with the key difference being their width. The S62200 bearing has a width of 14mm, while the S6200 bearing's width is 9mm. Despite the difference in width, both series feature identical internal structures, including the same steel ball size, cage dimensions, and number of steel balls.
The current S62200 series bearing models(AISI 420) available in our company's warehouse are as follows. The delivery time has been shortened to 3 days. We can also produce non-standard bearings. For specific delivery dates, please get in touch with
| type | d(mm) | D(mm) | B(mm) | Cr（KN) | Cor（KN) | rpm（grease） | rpm（oil） | weight（Kg) |
| S62200 ZZ/2RS | 10 | 30 | 14 | 5.07 | 2.36 | 17000 | 19000 | 0.0480 |
| S62201 ZZ/2RS | 12 | 32 | 14 | 6.89 | 3.10 | 15000 | 17000 | 0.0530 |
| S62202 ZZ/2RS | 15 | 35 | 14 | 7.80 | 3.75 | 13000 | 15000 | 0.0650 |
| S62203 ZZ/2RS | 17 | 40 | 16 | 9.56 | 4.75 | 12000 | 14000 | 0.0960 |
| S62204 ZZ/2RS | 20 | 47 | 18 | 12.70 | 6.55 | 10000 | 12000 | 0.1450 |
| S62205 ZZ/2RS | 25 | 52 | 18 | 14.00 | 7.80 | 8500 | 10000 | 0.1720 |
| S62206 ZZ/2RS | 30 | 62 | 20 | 19.50 | 11.20 | 7500 | 9500 | 0.2750 |
| S62207 ZZ/2RS | 35 | 72 | 23 | 25.50 | 15.30 | 6500 | 7500 | 0.4100 |
| S62208 ZZ/2RS | 40 | 80 | 23 | 30.70 | 19.00 | 5600 | 6500 | 0.6200 |
| S62209 ZZ/2RS | 45 | 85 | 23 | 33.20 | 21.60 | 5000 | 6000 | 0.6300 |
| S62210 ZZ/2RS | 50 | 90 | 23 | 35.10 | 23.20 | 4800 | 5500 | 0.7300 |
